application

1.Temporary fixation of electronic components to avoid scratches and damage to the product

2.Exquisite and fragile chip processing; Positioning and cutting of MLCC chip capacitors and chip inductors in the manufacturing process

3.Semiconductor chip surface processing; Manufacturing and processing engineering of electronic and optoelectronic industry components

4.Perform wafer cutting or substrate cutting for semiconductor wafer factories; Back grinding; Protective film used in the thinning process to protect surface circuits

5.LCD and TP touch panel glass thinning, grinding and polishing

6.LED cutting, grinding and polishing; Thin Grinding Process for Sapphire Substrates

7.Copper substrate graphene transfer printing and nanocarbon tube transfer printing can replace UV blue film for use

Property

description

Features

1. PET material: Polyethylene terephthalate (PET) is used as the base material, with high transparency, high strength and weather resistance.

2. Environmentally friendly adhesive: Use green and environmentally friendly adhesive, meet environmental protection standards, and is harmless to the human body and the environment.

3. Thermal decomposition performance: In a high temperature environment, the adhesive will automatically decompose and can be easily peeled off without leaving any residual adhesive.

4. High transparency: High transparency design does not affect the visibility of the protected material.

5. Scratch resistance: The surface hardness is high, which can effectively prevent the protected material from being scratched during transportation and processing.

6. Easy to peel: It can be easily peeled off without using chemical solvents, reducing secondary pollution.

7. Wide range of applications: Suitable for surface protection of various materials such as glass, metal, and plastic.
