application
1. Used for pasting of backlight modules, fixing and pasting of electronic and electrical components, dust-proof nets, LED reflection molds and other parts.
2. Bonding and fixing of nameplates and membrane switches in the home appliance industry.
3. Paste and fix FPC.
4. Paste and fix the internal structure of OLED.
5. The module is fixed by pasting the protective film.
6. Temporary fixing and pasting of mobile phone parts.
7. Paste the graphite sheet inside the mobile phone.
8. Paste and fix the rubber feet.
9. Paste the sprayed board on the mesh surface of the microwave oven door.
Property
| Color | Total Thickness [um] | Backing [mm] | Adhesive | Initial Tack [mm] | 180°Peel Strength [N/inch] | Retentivity [hour] | Long-Term Temperature Resistance [℃] | Short-Term Temperature Resistance [℃] |
| Transparent | 10 | 0.002 | Acrylic | ≤100 | A&B≥10 | ≥24 | 80 | 120 |
| Transparent | 20 | 0.0045 | Acrylic | ≤100 | A&B≥12 | ≥24 | 80 | 120 |
| Transparent | 30 | 0.006 | Acrylic | ≤100 | A&B≥13 | ≥24 | 80 | 120 |
| Transparent | 50 | 0.012 | Acrylic | ≤100 | A&B≥15 | ≥24 | 80 | 120 |
| Transparent | 100 | 0.012 | Acrylic | ≤100 | A&B≥20 | ≥24 | 80 | 120 |
description
Characteristics
Physical characteristics
Ultra-thin: The thickness is usually between 0.005mm-0.05mm, such as Nitto's No.5600, which can reach 0.005mm.
Transparency: It has high transparency and has little effect on the appearance and visual effect of the adherend, and has obvious advantages in applications such as electronic screens.
Flexibility: The PET substrate gives the tape good flexibility, which can adapt to the bonding of various curved and irregular surfaces.
Chemical characteristics
Heat resistance: The long-term use temperature is generally 100℃-120℃, and it can withstand high temperatures of 140℃-200℃ in the short term.
Chemical resistance: It has good tolerance to common organic solvents, acids and alkalis and other chemical substances, and can maintain stable performance in different chemical environments.
Environmental protection: It adopts environmentally friendly formulas such as halogen-free, and some products have passed REACH certification and meet environmental protection requirements.
Adhesive properties
High viscosity: It has good adhesive properties for metal, plastic, glass, rubber and other materials, and the 180° peel strength can reach 3N/20mm-10N/20mm.
Good initial adhesion: It can quickly achieve adhesive positioning, which is easy to operate and process.
Strong lasting adhesion: It can maintain a stable bonding effect under long-term use and different environmental conditions, and it is not easy to fall off.
Application field
Electronic field
Smartphone: used for screen frame bonding, camera module fixation, battery and motherboard connection, flexible circuit board pasting, etc.
Tablet computer: It plays a role in display assembly and internal component fixation.
Laptop computer: It can be used for bonding keyboards, touchpads, heat sinks and other components.
Automotive field
Interior assembly: Bonding plastic parts and decorative strips of automobile dashboards and center consoles.
Automotive electronics: Fixing electronic components such as automobile sensors, circuit boards, and displays.
Medical field
Wearable medical devices: Used to fit sensors and housings, connect flexible circuits, etc.
Medical instruments: used to bond plastic, metal and other parts in the assembly of medical instruments.
Optical field
Optical lens: fix optical components such as lenses and shading sheets to ensure the stability of the optical system.
Display module: used to bond optical films such as polarizers and diffusers in liquid crystal display modules and OLED display modules.
