application
1. Nameplates, labels, signs: used in screen printing, advertising, aviation, medical and industrial equipment, automobiles, home appliances, electronic markets and other industries.
2. Soft board FPC: used in mobile phones, notebook computers, PDAs, digital cameras, LCM and other electronic products.
3. Membrane switch: including flexible, rigid, concave-convex and other types of membrane switches.
4. Anti-shock foam: good Initial Tack and stickiness, high cohesion, and good plasticization resistance.
Property
| Product Code Technical Parameters | P3305 | P3306H | P3306N | P3310 | P3313 | P3313H | P3313N |
| Color | Transparent | ||||||
| Total Thickness[mm] | 0.05 | 0.06 | 0.06 | 0.1 | 0.13 | 0.13 | 0.13 |
| Adhesive | Acrylic | Acrylic | Acrylic | Acrylic | Acrylic | Acrylic | Acrylic |
| Initial Tack[mm] | ≤100 | ≤100 | ≤100 | ≤100 | ≤100 | ≤100 | ≤100 |
| 180°Peel Strength[N/inch] | 18 | 13 | 13 | 12 | 18 | 18 | 18 |
| Retentivity[hour] | 24 | 24 | 24 | 24 | 24 | 24 | 24 |
| Long-Term Temperature Resistance [℃] | 80 | 150 | 150 | 80 | 80 | 150 | 150 |
| Short-Term Temperature Resistance [℃] | 120 | 200 | 200 | 120 | 150 | 200 | 200 |
description
Good compatibility: It has excellent bonding effect on surfaces of different materials, such as metal, plastic, glass, rubber, ceramic, etc., and can meet the connection requirements between different materials.
Excellent weather resistance: It has strong resistance to heat, moisture, UV rays, etc., and can maintain stable viscosity and physical properties under different environmental conditions, such as high temperature, low temperature, humidity, sunlight, etc., and is not prone to aging, degumming and other problems.
Thin and flexible: It is usually thin and has good flexibility. It can fit well on objects of various shapes and surfaces. Even curved surfaces, corners or uneven surfaces can be tightly adhered without affecting the appearance and performance of the adherend.
No residual glue: Under normal use conditions, when the tape is torn off, no residual glue will be left on the surface of the adhered object, and the surface of the adhered object will not be polluted or damaged, which is convenient for subsequent cleaning and processing.
Good processing performance: It can be easily processed by die cutting, punching, slitting and other processing operations. It can be processed into tape products of various shapes and sizes according to different usage requirements to meet diverse application scenarios.
Application fields
Electronic field: used in electronic devices such as mobile phones, tablets, and laptops, it can be used to paste and fix display screens, cameras, batteries, graphite heat sinks and other components; in the production of printed circuit boards (PCBs), it is used to protect sensitive electronic components and prevent them from being damaged during processing, while helping to accurately position and paste tiny electronic components.
Automobile field: It can paste automotive interior parts, such as decorative strips, sound insulation materials, etc.; in process links such as automotive painting, it is used to fix and protect parts to prevent parts that do not need to be painted from being sprayed by mistake.
Optical field: It can be used for the processing and protection of lenses and optical components to ensure the cleanliness and integrity of the surface. In the assembly of optical instruments, it is used to paste and fix optical lenses, prisms and other components.
Medical field: It can be used to fix and assemble some parts in medical equipment; in medical care, it is used to fix sensors, electrodes and other parts of medical monitoring equipment that come into contact with human skin, with good fit and comfort.
Aerospace field: used for sealing and connecting aircraft fuselage parts, able to maintain stable performance in extreme environments, ensuring the integrity and safety of aircraft structures; can also be used for fixing and bonding some parts in aerospace equipment.
Other fields: in the advertising and logo industry, used for pasting advertising posters, light box pieces, etc.; in handicraft production, can be used to fix and paste handicraft parts, etc.; in the packaging industry, used for sealing paper boxes and cartons to ensure the sealing of packaging during transportation and storage; can also be used for pasting labels and trademarks to ensure that the labels are firmly pasted and not easy to fall off.
