application
1.Main insulation recovery of solid medium cables below 69kV.
2.Moisture-proof sealing, intermediate joint and end sealing of medium and low voltage cables.
3.Waterproof insulation sealing of the line core connector on the medium-voltage and low-voltage joints.
4.Bus insulation.
Property
| Test items | Typical value | Unit | Test method |
| color | black | – | Visual inspection |
| Release material | Release paper | – | – |
| texture of timber | Ethylene propylene rubbe | – | – |
| thickness | 0.76 | mm | ASTM D-3652 |
| Tensile strength | ≥2.0 | Mpa | ASTM D-3759 |
| elongation | ≥500% | % | ASTM D-3759 |
| Self-adhesive | No loosening | ℃ | Q/CCJN-06-2001 |
| Volume resistivity | ≥3×1015 | Ω·cm | GB/T 1692-2008 |
| Breakdown strength | ≥25 | kV/mm | GB/T 1695-2005 |
| Use temperature | -40-110 | ℃ | – |
| dielectric constant | 2-3 | – | GB/T 1693-2007 |
description
Features
1. Excellent weather resistance: UV resistance, ozone resistance, high and low temperature resistance (-40°C to +120°C).
2. Self-adhesive properties: The backing is strong, no additional adhesive is required, and it is easy to install.
3. Corrosion resistance: Resistant to chemical substances and oil pollution, suitable for use in harsh environments.
4. Waterproof sealing: Effectively prevents water vapor penetration and provides reliable sealing effect.
5. Electrical insulation: Suitable for insulation and protection of electrical equipment.
6. Flexibility: Easy to bend and fit complex surfaces.
7. Durability: Wear-resistant, aging-resistant, and long service life.
8. Environmental protection: No harmful substances, in line with environmental protection standards.
9. Multiple colors: Commonly black, other colors can also be customized.
10. Economical and practical: High cost performance, it is a high-quality alternative to 3M23 tape.
Application areas
1. Electrical insulation
Used for insulation protection of wires, cables and electrical equipment.
2. Pipeline protection
Used for waterproof sealing and anti-corrosion protection of pipeline joints.
3. Building waterproofing
Used for waterproof sealing of roofs, windows and wall joints.
4. Automobile industry
Used for sealing and protection of automobile wiring harnesses, pipes and joints.
5. Air conditioning and refrigeration equipment
Used for insulation and waterproof sealing of pipes and joints.
6. Industrial equipment
Used for waterproof, dustproof and anti-corrosion protection of mechanical equipment.
7. Solar equipment
Used for waterproofing and insulation of solar panel joints.
8. Shipbuilding and marine engineering
Used for waterproofing and anti-corrosion protection of ship pipes and joints.
9. Wind energy equipment
Used for insulation and sealing protection of wind turbines.
10. Other fields
Used in various application scenarios that require waterproofing, insulation or anti-corrosion.
