application

Used in the packaging industry for medical devices, food, electronic equipment, etc.

Wear-resistant coatings for internal surfaces of mechanical equipment, conveyor systems, etc.

Used to make pipe linings, seals for valves, pumps and other fluid control equipment.

Protective wear layer for sports and protective equipment.

Good insulation and mechanical protection as cable sheath material.

Property

Test items	Typical value	Unit	Test method
Backing thickness	0.08	mm	GB/T7125-2014
Adhesive thickness	0.05	mm	GB/T7125-2014
Total thickness	0.13	mm	GB/T7125-2014
Adhesion to steel	≥8	N/25mm	GB/T2792-1998
Density	0.93～0.95	g/cm³	ASTM D792
Molecular weight	350～920	10⁴g/mol	ASTM D4020
Water absorption	＜0.01	%	ASTM D570
Tensile Strength	38	Mpa	GB/T 1040.3-2006
Bending strength	26	Mpa	GB/T 1040.3-2006
Elongation at break	50	%	GB/T 1040.3-2006
Compressive strength (10%)	27	Mpa	ASTM D695
Shear strength	33	Mpa	ASTM D695
Shore hardness	60~63	D	ASTM D2240
Coefficient of friction	–	0.07～0.11	ASTM D1894
Temperature resistance	℃	-269～90	ASTM D4894
Thermal expansion coefficient	℃^-1	1.5×10^-4	GB1036-1989
Abrasion rate	mg	80	GB/T 3960-1989
Dielectric breakdown strength	Kv/mm	45	IEC 60243-2:2001
lSurface charge rate	Ohm	10¹⁵	ASTM D257

Product Features

1.Excellent wear resistance, good chemical stability.

2.Excellent impact resistance, low coefficient of friction and self-lubricating properties.

3.High strength and high toughness, light weight.

4.Low temperature resistance, electrical insulation properties, and environmental hygiene.
