PROPERTIES | UNITS | AM12 | AM15 | AM20 | AM25 | AM30 | TEST METHOD |
Color | / | White Grey | White Grey | Grey | Orange | Blue | Visual |
Thermal impedance @1mm/20Psi | ℃in2/W | 0.8 | 0.7 | 0.5 | 0.47 | 0.42 | ASTM D5470 |
Specific Gravity | g/cm3 | 1.8 | 2 | 2.4 | 2.9 | 3 | ASTM D792 |
Volume Resistivity | ΩCM | 5.0×1013Ω | 5.0×1013Ω | 2.6×1013Ω | 1.5×1013Ω | 1.0×1014Ω | ASTM D257 |
Thermal Conductivity | W/mk | 1.2 | 1.5 | 2 | 2.5 | 3 | ASTM D5470 |
Breakdown Voltage | KV/mm | ≧10 | ≧10 | ≧10 | ≧10 | ≧9 | ASTM D149 |
Dielectric Constant@1MHz | @1MHz | 5.5 | 5.5 | 6 | 5.5 | 5.6 | ASTM D150 |
Thickness (±10%) | mm | 0.2~10 | 0.2~10 | 0.2~10 | 0.3~5.0 | 0.3~5.0 | ASTM D374 |
Hardness | Shore 00 | 35/50 | 35/50 | 35/50 | 35/50 | 35/50 | ASTM D2240 |
Flammability class | / | UL94-VO | UL94-VO | UL94-VO | UL94-VO | UL94-VO | UL94 |
Application temperature | ℃ | -50~+200 | -50~+200 | -50~+200 | -50~+200 | -50~+200 | *** |
Tape Choose | / | ∨ | ∨ | ∨ | ∨ | ∨ | *** |
Self-adhesive | / | Double sided | Double sided | Double sided | Double sided | Double sided | *** |
Fiber Strengthen | / | ∨ | ∨ | ∨ | ∨ | ∨ | *** |
PROPERTIES | UNITS | AM40 | AM50 | AM60 | AM80 | TEST METHOD |
Color | / | Brown | Dark Red | Light Grey | Grey | Visual |
Thermal impedance @1mm/20Psi | ℃in2/W | 0.36 | 0.21 | 0.2 | 0.15 | ASTM D5470 |
Specific Gravity | g/cm3 | 2.8 | 3 | 3.2 | 3.4 | ASTM D792 |
Volume Resistivity | ΩCM | 1.0×1014Ω | 1.0×1014Ω | 1.0×1013Ω | 1.0×1013Ω | ASTM D257 |
Thermal Conductivity | W/mk | 4 | 5 | 6.5 | 8 | ASTM D5470 |
Breakdown Voltage | KV/mm | ≧9 | ≧10 | ≧10 | ≧8 | ASTM D149 |
Dielectric Constant@1MHz | @1MHz | 5 | 5 | 5 | 7.5 | ASTM D150 |
Thickness (±10%) | mm | 0.5 ~5.0 | 0.5 ~5.0 | 0.5 ~5.0 | 0.5 ~5.0 | ASTM D374 |
Hardness | Shore 00 | 50 | 55 | 60 | 70±10 | ASTM D2240 |
Flammability class | / | UL94-VO | UL94-VO | UL94-VO | UL94-VO | UL94 |
Application temperature | ℃ | -50~+200 | -50~+200 | -50~+200 | -40~+150 | *** |
Tape Choose | / | ∨ | ∨ | ∨ | ∨ | *** |
Self-adhesive | / | Double sided | Double sided | Double sided | Double sided | *** |
Fiber Strengthen | / | ∨ | ∨ | ∨ | ∨ | *** |
