The AYMT520CL is suitable for applications such as protecting and fixing electronic components on circuit boards. It has strong adhesion, excellent adhesion and stretchability, and leaves no residue after peeling off after continuous baking.
Product Information
| Metric | |
| Total thickness | 145 μm± 10μm |
| Tensile strength | ≥65 N/25mm |
| elongation | ≥8 % |
| Peel strength (to steel plate) | ≥6.5 N/25mm |
| Initial bonding | ≥10 |
| Temperature resistance (30 min) | 80℃ |
| Backing material | Crepe paper |
| Adhesive type | natural rubber |
| Available colors | yellow |
Product Features:
• Clear boundaries, neat masking lines;
• Easy to peel and apply, long-lasting adhesion;
• Smooth paper tape surface, leaves no residue after application, and will not damage components.
Product Applications: Circuit board drill hole protection, component protection or fixation.
