application
1. Used for pasting of backlight modules, fixing and pasting of electronic and electrical components, dust-proof nets, LED reflection molds and other parts.
2.Bonding and fixing of nameplates and membrane switches in the home appliance industry.
3. Paste and fix FPC. 4. Paste and fix the internal structure of OLED.
5. The module is fixed by pasting the protective film.
6. Temporary fixing and pasting of mobile phone parts.
7. Paste the graphite sheet inside the mobile phone.
8. Paste and fix the rubber feet. 9. Paste the sprayed board on the mesh surface of the microwave oven door.
Property
| Product Code | Color | Total Thickness [um] | Backing [mm] | Adhesive | Initial Tack [mm] | 180°Peel Strength [N/inch] | Retentivity [hour] | Long-Term Temperature Resistance [℃] | Short-Term Temperature Resistance [℃] |
| P3205A | Transparent | 50 | 0.012 | Acrylic | ≥100 | ≥11 | ≥24 | 80 | 120 |
| P3205A+ | Transparent | 50 | 0.012 | Acrylic | ≥100 | ≥14 | ≥24 | 80 | 120 |
| P3210A | Transparent | 100 | 0.012 | Acrylic | ≥100 | ≥20 | ≥24 | 80 | 120 |
| P3210A+ | Transparent | 100 | 0.012 | Acrylic | ≥100 | ≥24 | ≥24 | 80 | 120 |
| P3210AA | Transparent | 100 | 0.012 | Acrylic | ≥100 | ≥20 | ≥24 | 80 | 120 |
description
Features
High adhesion: It uses high-performance pressure-sensitive adhesive, which has strong adhesion to a variety of materials such as metal, plastic, glass, rubber, etc., can ensure the firmness and durability of the paste, and can maintain a stable bonding effect for a long time.
Excellent temperature resistance: It can generally withstand temperatures of 100-125℃ for a long time, and can withstand high temperatures of 150-200℃ for a short time. In high temperature environments, the viscosity and physical properties are stable, and it is not easy to have problems such as melting and degumming.
Good weather resistance: The PET substrate has high chemical stability, and the tape has excellent weather resistance. It can resist the influence of environmental factors such as ultraviolet radiation, humidity and aging, and can maintain stable performance under different environmental conditions.
High tear resistance: The PET film has high mechanical strength and tear resistance, which makes the tape not easy to tear during use, can withstand large tension and shear force, and is suitable for various high-stress environments.
Dimensional stability: Under different temperature and humidity conditions, the dimensional change is minimal, which can ensure that in applications with high precision requirements, a stable bonding effect is maintained, and the product performance will not be affected by dimensional changes.
Good flexibility: PET film itself has a certain flexibility, so that the tape can be well attached to objects of various shapes and surfaces, even curved or uneven surfaces, and can be tightly attached.
Easy to process: It can be easily processed by die-cutting, punching and other processing operations, and can be processed into tape products of various shapes and sizes according to different usage requirements to meet diverse application scenarios.
No residual glue: Under normal use conditions, when the tape is torn off, no residual glue will be left on the surface of the adhered object, and the surface of the adhered object will not be polluted or damaged, which is convenient for subsequent cleaning and processing.
Application field
Electronic field: It is used in electronic devices such as mobile phones, tablets, and laptops to fix display screens, cameras, batteries, graphite heat sinks and other components; it can also be used for packaging of electronic components, insulation and fixation of circuit boards, etc., and can maintain stable performance in processes such as high-temperature welding.
Automotive field: It can be used to paste automotive interior parts, such as decorative strips, sound insulation materials, etc.; it can also be used for sealing car lights, fixing car logos and nameplates, etc., and can withstand environmental factors such as vibration, high temperature and humidity during car driving.
Building decoration field: It can be used to paste decorative panels, wallpapers, wall cloths, etc., so that decorative materials are firmly combined with the wall, ground and other base layers; it can also be used to fix the sealing strips of building doors and windows, paste building logos, etc., with good weather resistance and can maintain the bonding effect for a long time.
Packaging field: In the packaging industry, it can be used to seal paper boxes and cartons to ensure the sealing of packaging during transportation and storage; it can also be used to paste labels and trademarks to ensure that the labels are firmly pasted and not easy to fall off.
Medical field: It can be used to fix and assemble some parts in medical equipment; in medical care, it can also be used to fix sensors, electrodes and other parts of medical monitoring equipment that are in contact with human skin, with good fit and comfort.
Other fields: In the advertising and signage industry, it is used to paste advertising posters, light box pieces, etc.; in handicraft production, it can be used to fix and paste handicraft parts, etc.; it can also be used in furniture manufacturing to fix decorative parts, connecting parts, etc.
