application
1. Used for pasting of backlight modules, fixing and pasting of electronic and electrical components, dust-proof nets, LED reflection molds and other parts.
2. Bonding and fixing of nameplates and membrane switches in the home appliance industry.
3. Paste and fix FPC.
4. Paste and fix the internal structure of OLED.
5. The module is fixed by pasting the protective film.
6. Temporary fixing and pasting of mobile phone parts.
7. Paste the graphite sheet inside the mobile phone.
8. Paste and fix the rubber feet.
9. Paste the sprayed board on the mesh surface of the microwave oven door.
Property
Product Code | Color | Total Thickness [um] | Backing [mm] | Adhesive | Initial Tack [mm] | 180°Peel Strength [N/inch] | Retentivity [hour] | Long-Term Temperature Resistance [℃] | Short-Term Temperature Resistance [℃] |
| P3203B | Black | 30 | 0.012 | Acrylic | ≤150 | ≥7 | ≥24 | 80 | 120 |
| P3205B | Black | 50 | 0.012 | Acrylic | ≤150 | ≥8 | ≥24 | 80 | 120 |
| P3208B | Black | 80 | 0.012 | Acrylic | ≤120 | ≥10 | ≥24 | 80 | 120 |
| P3210B | Black | 100 | 0.025 | Acrylic | ≤100 | ≥12 | ≥24 | 80 | 120 |
| P3213B | Black | 125 | 0.025 | Acrylic | ≤100 | ≥14 | ≥24 | 80 | 120 |
| P3216B | Black | 160 | 0.025 | Acrylic | ≤100 | ≥15 | ≥24 | 80 | 120 |
| P3220B | Black | 205 | 0.025 | Acrylic | ≤100 | ≥17 | ≥24 | 80 | 120 |
description
Features
High adhesion: Generally, acrylic pressure-sensitive adhesive is used, which can achieve firm adhesion to various materials such as metal, plastic, glass, rubber, ceramic, etc., and can meet the bonding requirements between different materials.
Good shielding: The black PET substrate has excellent light-shielding performance and can effectively block light transmission. It can be used in occasions where light-shielding is required, such as light-shielding treatment of electronic equipment display screens.
Good temperature resistance: The long-term use temperature can reach 100-120℃, and it can withstand high temperatures of about 140℃ in a short period of time. In a high temperature environment, the viscosity and physical properties of the tape remain stable, and it is not easy to melt, degumming and other problems.
Chemical stability: It has good tolerance to common acids, alkalis, organic solvents, etc., and can maintain stable performance in different chemical environments, and is not easy to be corroded or decomposed.
Good flexibility: The PET film itself has a certain flexibility, which allows the tape to fit well on objects of various shapes and surfaces, even curved or uneven surfaces, and can achieve tight adhesion.
Dimensional stability: Under different temperature and humidity conditions, the size of the tape changes very little, which can ensure that in applications with high precision requirements, such as the pasting of electronic components, a stable bonding effect is maintained, and the product performance will not be affected by size changes.
Easy to process: It can be easily processed by die-cutting, punching and other processing operations, and can be processed into tape products of various shapes and sizes according to different usage requirements to meet diverse application scenarios.
No residual glue: Under normal use conditions, when the tape is torn off, no residual glue will be left on the surface of the adhered object, and the surface of the adhered object will not be polluted or damaged, which is convenient for subsequent cleaning and processing.
Application field
Electronic field: It is used in electronic devices such as mobile phones, tablets, and laptops to paste and fix display screens, cameras, batteries, graphite heat sinks and other components; it can also be used for the packaging of electronic components, the insulation and fixation of circuit boards, etc.
Automotive field: It can paste automotive interior parts, such as decorative strips, sound insulation materials, etc.; it can also be used for the sealing of automotive lights, the fixing of automotive logos and nameplates, etc.
Building decoration field: It can be used to paste decorative panels, wallpapers, wall cloths, etc., so that the decorative materials are firmly combined with the wall, ground and other base layers; it can also be used to fix the sealing strips of building doors and windows, paste building signs, etc.
Packaging field: In the packaging industry, it can be used to seal paper boxes and cartons to ensure the sealing of the packaging during transportation and storage; it can also be used to paste labels and trademarks to ensure that the labels are firmly pasted and not easy to fall off.
Medical field: It can be used to fix and assemble some parts in medical equipment; in medical care, it can also be used to fix the sensors, electrodes and other parts of medical monitoring equipment that contact the human skin, with good fit and comfort.
Other fields: In the advertising and identification industry, it is used to paste advertising posters, light box pieces, etc.; in handicraft production, it can be used to fix and paste parts of handicrafts, etc.
