application
1. Bonding of rubber strips and plastics in the rubber and plastic industry.
2. It is suitable for bonding nameplates, buttons, foot pads, refrigerator evaporators and control panels.
3. Bonding of low surface energy PP and PE plastic home appliance display boards.
4. Stamping metal signage.
5. Bonding and fixing the heating wire of the smart rice cooker.
6. Bonding and fixing of speaker nets of TV and computer speakers.
7. Foam sealing and pasting of EPDM and PU foam.
8. Paste the cotton blanket on the top of the car.
9. Paste the back panel of the upper cover of the printer.
10. In the paper industry, manual splicing process, super rolling process, resin coating process and roll changing joint.
11. Temporary fixation for computerized embroidery.
12. Paper box pasting for general ornaments, temporarily fixing handicrafts.
Property
Product Code | Color | Total Thickness [um] | Backing | Adhesive | Initial Tack[mm] | 180°Peel Strength [N/inch] | Retentivity [hour] | Long-Term Temperature Resistance [℃] | Short-Term Temperature Resistance [℃] |
| P3105H | Translucent | 50 | Tissue | Acrylic | ≤100 | ≥9 | 24 | 80 | 120 |
| P3110H | Translucent | 100 | Tissue | Acrylic | ≤100 | ≥11 | 24 | 80 | 120 |
| P3112H | Translucent | 120 | Tissue | Acrylic | ≤100 | ≥13 | 24 | 80 | 120 |
| P3114H | Translucent | 140 | Tissue | Acrylic | ≤100 | ≥15 | 24 | 80 | 120 |
| P3116H | Translucent | 160 | Tissue | Acrylic | ≤100 | ≥16 | 24 | 80 | 120 |
| P3110B | Black | 100 | Tissue | Acrylic | ≤100 | ≥11 | 24 | 80 | 120 |
| P3112B | Black | 120 | Tissue | Acrylic | ≤100 | ≥13 | 24 | 80 | 120 |
| P3114B | Black | 140 | Tissue | Acrylic | ≤100 | ≥15 | 24 | 80 | 120 |
| P3116B | Black | 160 | Tissue | Acrylic | ≤100 | ≥16 | 24 | 80 | 120 |
| P3112N | Translucent | 120 | Tissue | Acrylic | ≤100 | ≥12 | 24 | 120 | 150 |
| P3114N | Translucent | 140 | Tissue | Acrylic | ≤100 | ≥14 | 24 | 120 | 150 |
| P3116N | Translucent | 160 | Tissue | Acrylic | ≤100 | ≥15 | 24 | 120 | 150 |
| P3110 | Translucent | 100 | Tissue | Acrylic | ≤100 | ≥11 | 24 | 40 | 60 |
| P3112 | Translucent | 120 | Tissue | Acrylic | ≤100 | ≥13 | 24 | 40 | 60 |
| P3114 | Translucent | 140 | Tissue | Acrylic | ≤100 | ≥14 | 24 | 40 | 60 |
| P3116 | Translucent | 160 | Tissue | Acrylic | ≤100 | ≥15 | 24 | 40 | 60 |
description
Features
High adhesion: It uses high-performance acrylic pressure-sensitive adhesive, which has strong adhesion to the surfaces of various materials such as metal, plastic, glass, foam, fabric, etc., and can ensure the firmness and durability of the paste.
Anti-rebound: Compared with other double-sided tapes, it has better anti-rebound performance when pasted on curved or irregular surfaces, can fit the curved surface tightly, and is not easy to rebound and warp.
Anti-warping: It has excellent anti-warping performance, and can remain flat even after long-term use or under different environmental conditions, without obvious curling or deformation.
Good heat resistance: Some products can withstand temperatures of 80℃-120℃ for a long time, and can withstand temperatures of 120℃-150℃ or even higher in a short time, and can maintain stable viscosity and use effect in high temperature environments.
Good flexibility: It uses cotton paper as the base material, has a soft texture, good flexibility and fit, can adapt to the pasting needs of different shapes and surfaces, and can show good compliance when fitting curves and uneven surfaces.
Easy to tear and use: Generally covered with easy-to-peel release material, it can be easily torn off when used, and no residual glue will be left on the surface of the adhered object.
Dimensional stability: The cotton paper substrate gives the tape good dimensional stability. Under different temperature and humidity conditions, the dimensional change is minimal, which can ensure a stable bonding effect in applications with high precision requirements.
Solvent resistance: It has a certain tolerance to some common organic solvents. When exposed to a small amount of solvent, it is not easy to be dissolved or the viscosity is destroyed.
Application field
Automotive field
Interior assembly: used to paste automotive interior parts, such as cotton blankets, decorative strips, sound insulation materials, etc. on the ceiling to ensure the beauty and stability of the interior.
Wire harness fixing: Fix the wire harness inside the car to arrange it neatly to prevent the wire harness from shaking or friction causing damage.
Electronic field
Component fixing: In the assembly of electronic equipment, it is used to fix components such as circuit boards, display screens, batteries, chips, etc. to ensure the stability and reliability of electronic equipment.
Label pasting: Paste labels, logos, etc. on electronic equipment to ensure that the labels are not easy to fall off, and at the same time do not affect the appearance and performance of the equipment.
Home appliance field
Panel pasting: used to paste the control panel, display panel, etc. of home appliances to make them firmly combined with the body.
Fixing of heating components: such as fixing the heating wire and other heating components of smart rice cookers to ensure that they will not shift during operation.
Building decoration field
Pasting of decorative materials: can be used to paste decorative materials such as wallpaper, wall cloth, tiles, and wood veneer panels, providing a uniform and smooth pasting effect, making the decoration more beautiful and firm.
Sealing and fixing: It is also used in the sealing of some building gaps and the fixing of small components, such as the fixing of door and window sealing strips.
Packaging and printing field
Carton sealing: used for sealing and pasting cartons to ensure that cartons will not be easily opened during transportation and storage.
Label pasting: Paste labels, trademarks, etc. on product packaging to ensure that the labels are firmly pasted and not easy to fall off.
Printing assistance: During the printing process, it can be used to fix materials such as paper and film to assist the printing process.
Other fields
Shoemaking and leather industry: used for gluing shoe materials and splicing leather, such as gluing and fixing insoles, heels and other parts to the shoe body.
Crafts and gifts industry: used for assembling and fixing crafts and gifts, such as gluing decorations and fixing the lining of gift boxes.
